Omni Power Station 20+ 120v

Power Station

10 Bay
Weight w/ units: 18.6 kg (41.1 lbs)
Dimensions w/ units: 530 mm x 179 mm x 250 mm (20.8 x 7 x 9.8 in)
Operating environment: Temperature 0°C-40°C，Humidity 30-70%，Altitude ≤2000m

Input: 100V-240V~,50/60Hz, up to 10A
Output: 24V 2A (per charging bay)

Omni Power 20+ For Power Station

Weight: 1.39 lbs (631.3 g)
Dimensions: 5.0″ x 4.8″ x 1.1″ (12.7 x 12.2 x 2.7 cm)
Combined output all ports: 100W

AC/HVDC Port

120V AC, 60Hz, 100W max US version
230V AC, 50Hz, 100W max EU version

USB-C Port

PD enabled bidirectional charging
Input: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A 18W max
Output: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A 60W max

USB-A Output

Port1: QC 3.0, 5V/3A,9V/2A,12V/1.5A
Port2: QC 3.0, 5V/3A,9V/2A,12V/1.5A
18W Max

DC Port

Bidirectional input/output charging
Input: 5-25V, up to 3A, 18W max
Output: 5-25V, up to 5A, 100W max

Wireless Charging

Output: 10w

Battery

Cell Type: 18650 Li-ion battery
Capacity: 6 cells, 71Wh (+/- 5%)

What is included

Base Station
10 portable chargers
AC power cable
Instruction Manual

Safety

 AC Outlet

• Provides up to 100W of power, functioning like a standard wall socket (supports120V).
• Use this port for devices with larger chargers that use a wall plug, such as laptops, cameras, portable projectors and other portable electronics. Ensure power usage is under 100W.
• To determine power requirements of your device, find the voltage (V), current (A), or wattage (W) on your device's charger, label, or manual. For example, a laptop with “20V, 3A” needs 60W of power. If unsure, search your device model online with terms like "power requirements" for detailed specs.

USB-C Port

• Delivers up to 60W of power with Power Delivery (PD).
• Suitable for devices supporting USB-C PD, such as MacBooks or iPads. Confirm that your device’s power needs are within the 60W limit of this port, and make sure to use a High Wattage USC-C Cable.
• Can also be used as an input for quickly recharging the power bank.

USB-A Ports (x2)

• Each port offers up to 18W, suitable for legacy USB devices like smartphones, headphones, and other accessories.

DC Input/Output Port

• Adjustable from 1V to 25V with up to 100W output, designed for specialized devices like drones, portable monitors, and custom electronics.
• Set the voltage and current on the OLED display to match your device's requirements. Make sure the connector type (e.g., barrel size) is compatible. With our Laptop DC Tips, Omnicharge provides the most commonly used tips to charge your devices and recharge the Omnicharge with your laptop charger.
• Can also be used as an input for quickly recharging the power bank.

Wireless Charging Pad

• Qi-enabled wireless charging with up to 10W output, ideal for smartphones and earbuds that support wireless charging.
• Align your device properly on the pad closer to the back of the device to ensure optimal charging (consult the image above).

1. Which Power Station model should I install in my space?

That depends on the use case. But typically, we find organizations install these models in spaces. If you need help selecting a model, please contact us HERE:

2. How many Power Stations do I need for my space?

For optimal coverage, we recommend one Power Station per 25 people. If you need assistance to select a model, please contact us or fill out the business inquiry form.

3. Where should I deploy my Power Station?

To maximize the benefits of your Power Station, place it in a location that's easily accessible for all users. Ensure it's on a flat, stable surface with good ventilation, away from direct sunlight and heat sources. Keep it protected from moisture and corrosive materials. By following these simple safety guidelines, you can expect a dependable power source that keeps productivity seamless and uninterrupted.

4. How long does it take for the Power Station to fully recharge the batteries?

Typically, it takes about three to four hours for the Power Station to fully recharge the batteries. Our Omni Power Stations are equipped with Dynamic Power Protection firmware, ensuring charging efficiency and safety. Once a power bank reaches 100% charge, it will automatically disengage charging and allow itself to deplete to around 80% before re-engaging. This intelligent feature enhances the longevity of your power banks, though you may only notice it if the power banks aren't used frequently.

5. How many times can Omnicharge recharge a laptop on a single charge?

Below is a reference guide when recharging laptops using different omnicharge models:

NOTE: If you're using your laptop while charging, expect it to draw power primarily from the external battery first. The exact remaining usage time varies based on your laptop's specifications and the applications you have running. For precision and control over your energy consumption, simply consult the OLED screen on your Omnicharge. It provides real-time insights into power draw and battery status, helping you confidently manage your mobile power needs.

6. How long do the Omnicaharge batteries last?

Omnicharge devices are crafted with top-tier materials, including premium lithium-ion battery cells, designed to withstand day-to-day use in professional and dynamic environments. With proper care, you can rely on these power solutions for years of dependable service.

Note: The lifespan of your Omnicharge device may vary based on usage patterns, frequency of use, the types of devices being charged, output wattage, and other factors. To maximize the longevity and performance of your Omnicharge, we recommend the following best practices:

Rotate Battery Usage: Ensure balanced usage across all batteries in the station to maintain optimal performance.

Power Off When Not in Use: Switch off stations when they are not needed to conserve energy and extend battery life.

Optimal Environment: Position stations in a cool, well-ventilated area, away from heat sources and moisture to safeguard against environmental stress.

7. What are the power requirements for each Power Station?

Explore the power requirements for each of our Power Station Models in the table below:

We recommend connecting only one Power Station to a single wall outlet and avoiding using power strips/extenders. To avoid overloading, please ensure the station is connected to a socket suitable for the required power rating.

9. Tell me more about the safety features of the power stations?

The Power Station charging base comes with the following protection features:

• Shock-resistant aluminum casing with high-efficiency heat dissipation
• Smart Overheat Protection: Power recovers automatically when the temperature lowers to the normal operation threshold.
• Short Circuit Protection
• Over-Voltage Protection

Each portable Omnicharge unit is equipped with the following safety features:

• Flame retardant casing shell
• Balanced structure layout and heat management
• Proprietary battery balancing management
• Battery overcharging/discharging protection
• Battery under-voltage/over-voltage protection
• Comprehensive temperature protection - High / Low Temperature protection
• Comprehensive temperature sensors
• Short-circuit protection
• Overload protection
• Surge protection
• End protection
